Compression Limiters are designed to protect components of an assembly from the compressive loads generated when a bolt is tightened to its recommended torque.
Comprising three critical dimensions, compression limiters focus on a specific inside diameter, which will accommodate a required bolt, an outside dimension, designed to fit into a designed hole, and a length that is specific to the thickness of the material that should not be compressed.
Baker works with the customer’s designs but can assist in recommending dimensions and tolerances that will best function in your assembly.
Relying on years of tubular stamping and working with customers’ requirements to provide high quality parts that focus on functionality within your assembly, Baker will be able to assist you in fulfilling your assembly designs.
Purpose and Role of Compression Limiters
Compression limiters act as a safeguard in mechanical assemblies. They limit the compression applied by fasteners or bolts, preventing damage to materials, reducing assembly failures, and extending product life. By controlling the compressive force, our limiters support consistent torque performance and help maintain quality standards. Customers rely on us to provide components that integrate smoothly into production lines, whether for metal or plastic assemblies. Customers can provide assembly requirements, and we will confirm limiter dimensions and suitability before production.
Applications in the Plastic Moulding Industry
Our compression limiters are widely used in the plastic moulding industry. They protect delicate plastic components from cracking or warping during assembly. These limiters fit precisely within housings, brackets, and other plastic structures, maintaining proper alignment while preventing material stress. We can supply compression limiters for plastic moulding industry projects in volume or with custom specifications, providing fast turnaround for production schedules.
Design and Dimensional Details
Compression limiters are defined by three critical measurements:
- Inside Diameter (ID): Allows the bolt or fastener to pass through.
- Outside Diameter (OD): Presses securely into the designated hole or cavity.
- Length: Controls the material thickness that should not be compressed.
Baker Stamping can evaluate assembly requirements and recommend dimensions to ensure optimal performance. Customers receive limiters with precise tolerances that integrate reliably into their components, reducing the risk of assembly errors. CAD files or design specifications can be submitted so our engineers verify the correct limiter dimensions.
Materials and Production
Our compression limiters are produced from high-quality metals chosen for durability and consistent performance. Stamping offers precise, repeatable manufacturing that supports large-volume production without sacrificing accuracy. Customers can request sample parts or short production runs for testing before full-scale production. Baker Stamping provides support to adapt the limiter material or finish to meet specific assembly requirements.
Customer Benefits
Using our compression limiters delivers multiple advantages:
- Protects sensitive materials in metal and plastic assemblies.
- Maintains consistent torque and assembly integrity.
- Reduces part failure and assembly rework.
- Supports production efficiency with ready-to-install components.
Customers are encouraged to contact Baker Stamping to discuss production schedules, volume requirements, or special finishes to match their application needs.
Customization and Support
We work with customers to provide compression limiters that meet exact application needs. Our engineering team can review design files, confirm dimensional fit, and offer production advice for both short and long production runs. Contact us today to order compression limiters or discuss your assembly requirements.
